As a trusted FTTH Fiber Optic ODN Box supplier in China, Yuanyi integrates splicing, splitting, storage, and distribution into one robust unit, supporting high-bandwidth service delivery with minimal installation effort. Its pre-terminated design reduces on-site labor and accelerates deployment, making it ideal for both indoor and outdoor applications.
1.Fully Sealed Enclosure – Provides complete protection against water, dust, and aging.
2.High-Grade ABS Material – Weather-resistant, UV-stable, and rated IP65 for reliable outdoor performance.
3.All-in-One Functionality – Combines cable clamping, splicing, splitter mounting, and fiber storage in one organized unit.
4.Structured Routing Design – Separate paths for feeder cable, drop cables, and pigtails prevent tangling and simplify maintenance.
5.Flip-Up Tray Design – Easy access to splitters and adapters for quick installation and servicing.
6.Flexible Mounting Options – Supports wall or pole mounting, suitable for indoor and outdoor environments.
|
Model |
FTTH Fiber Optic ODN Box YY-H004 |
|
capacity |
8 fibers (SC/APC or SC/UPC) |
|
Port |
2 Inlet 8 Outlet |
|
Material |
ABS (IP65 rated) |
|
Size |
345*220*103mm |
|
Adapter (SC/APC or SC/UPC) |
8 pcs waterproof adapters (SC/APC or SC/UPC) |
|
Color |
White/Black/Gray/Custom |
|
Logo |
Customized |
|
Relative humidity |
≤85% (+30℃) |
|
Atmospheric pressure |
70~106KPa |
|
Operating Temperature |
-25℃~+45℃ |
|
Install |
Wall mount/pole mount |
|
Working environment |
Indoor and outdoor |
|
Return loss (dB) |
PC type≥45dB，UPC type≥50dB，APCtype≥60dB |
|
Connector life |
≥1000 |
Yuanyi is a professional FTTH Fiber Optic ODN Box Manufacturer committed to delivering durable, easy-to-install, and maintainable optical distribution solutions. Our boxes are designed to streamline ODN deployment and ensure long-term network reliability.
For projects seeking value without compromising quality, buy discount FTTH Fiber Optic ODN Box from Yuanyi — a cost-effective choice for network operators and installers.
We support customization in color, logo, and packaging. As a dedicated FTTH Fiber Optic ODN Box factory, Yuanyi works closely with partners to meet specific project requirements and delivery schedules.
Product Name: FTTH Fiber Optic ODN Box
Manufacturer: Yuanyi
Applications: FTTH/FTTB/FTTC optical distribution networks
MOQ & Pricing: Contact for details
Lead Time: Standard and expedited options available
Contact Yuanyi for your ODN needs — your reliable partner in optical access networks.
